Mains Input Voltage Range :     100 - 240 ± 10% VAC @ 47-63 Hz

Power consumption (max.) :     435W

Mains Fuse:                             100 - 240 V~      T 5.0A/250V

Internal Fuses:
PCB Ident                  Fuse type
F1 (+12V)                 T 6.3A 250V 20mm
F2 (+48V)                 T 1.6A 250V 20mm
F18 (aux psu)            T 500mA 250V 20mm

DC Outputs
DC Voltage Rail      Output Current
+17 VOLTS              6.5A Max.
-17 VOLTS               6.5A Max.
+12 VOLTS              4A Max.
+48 VOLTS              500mA Max.

DC Output Socket Pin Connections
Pin No:            Connection
1                     +12 Volts
2                     +17 Volts
3                     Chassis
4                     A GND
5                     D GND
6                     +48 Volts
7                     -17 Volts

• výška: 90
• hmotnost: 6
• šířka: 440
• hloubka: 260
